附图

作者：罗伯特·杰克逊 ·英国

出自————《B-17“空中堡垒”轰炸机》

出自————《战争通史》

　　 制作者谨注：以下各图并非《B－17“空中堡垒”轰炸机》一书原图，系制作者选自Osprey、Profile 等丛书，谨供参考。

　　线图

　　 All drawings on the following three pages are of a Boeing B-17E Flying Fortress at 1/108th scale. Increase in size by 1.5 to achieve 1/72nd scale

　 彩图

　　 BOEING B-17F-10-BO FLYING FORTRESS of the 324th Bombardment Squadron, 91st Bombardment Group. 1st Combat Wing. 1st Air Division, United States 8th Air Force. Bassingbourn, Cambridgeshire, England. 7th June 1943.

　　 “Memphis Belle” was the first 8th Air Force bomber to complete on operational tour of 25 combat mission and return to the U.S.

　　 BOEING B-17G-40-BO FLYING FORTRESS of 401st Bombardment Squadron, 91st Bombardment Group, 1st Combat Bombardment Wing, U.S. Eighth Army Air Force. Bassingbourn, Cambridgeshire, England. January 1945.

　　 “General Ike” was’ christened’ with a bottle of Mississippi River water by General Dwight Eisenhower, Supreme Commander, Allied Expeditionary Forces, in April 1944. The aircraft was engaged in combat operations from that month until the end of hostilities in Europe. Crew Chief: Master Sergeant McDaniels.
